Ceramic Immersion Bobbin Heater are used for heating fluids in boilers, water heaters and tanks, and can also be used for heating Air/gas in oven.This ceramic immersion bobbin heater is usually mounted on a welded or assembled tube, which makes it possible to change or replace the heating element without emptying the container.
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of ceramic immersion bobbin heater in China, also supports custom service. Welcome to wholesale high quality ceramic immersion bobbin heater at competitive price from our factory.
Ceramic Immersion Bobbin Heater
Ceramic Immersion Bobbin Heater are used for heating fluids in boilers, water heaters and tanks, and can also be used for heating Air/gas in oven. This ceramic immersion bobbin heater is usually mounted on a welded or assembled tube, which makes it possible to change or replace the heating element without emptying the container.
Specification of Ceramic Immersion Bobbin Heater:
1.Material:ceramic, Alumina,Steatite, Cordierite, Mullite for core. Use cramic with high-temperature strength and high temperature insulation capability, not broken and drain when work in high temperature.
2.High Temperature Resistance:High resistance, no impurities, no segregation, strong antioxidant capacity, no distortion, no breakdown, no loopholes phenomenon in use.
3.High mechanical strength
4.Good chemical capability and insulation
5.The size and specifications of the Ceramic Immersion Bobbin Heater can be customized based on customers’ requirements.
Technical Parameter of Ceramic Immersion Bobbin Heater:
1.Range tolerance of cold resistance of electric wire ≤3%
2.Insulation resistance between outside protector and electric resistance >2MΩ
3.Diameter of heater tube is from φ60mm~φ300mm
4.Power is from 2KW to 24kw
5.Length of heater tube is from 800 to 2800mm
6.Thickness of sleeve is from 1.5 to 16mm
Protection:
1. After using three to four months, take the ceramic heater, and pour-out the dust in the ceramic heater, and tuner the heater 180 degree.
2. Pay attention to the positive and negative pole, and two to four months make a change.
3. Can touch and hit the heater when take it out.
4. Check the screw regularly for the oxidation looseness,
Application of Ceramic Immersion Bobbin Heater:
Heating fluids in boilers, water heaters
Electronics industry
Automotive industry
Medical electronics
Automobile industry
Avionics
Solid Oxide Fuel Cells
White goods
High power/High temperature application
Order Guide:
1-What is the heating condition of the ceramic bobbin heater will be used in.
2-What is the required working temperature
3-The diameter of the Ceramic heater need
4-The length of the ceramic heater
5-The Voltage and watt
6-Any speical requirement, drawing will be prefered.
