Cartridge Oil Heater
The cartridge oil heater has an inner lead and an outer wiring structure. The common lead is protected by a high-temperature casing. Metal hose, braided wire, high-temperature porcelain can be added as required to protect the lead. The standard heating tube lead is 200mm, and the bottom of the tube and the terminal are according to The cold end is required to be reserved, and the power can be produced in sections. The cartridge oil heater can be divided into straight rod type without fasteners, threaded installation type, limit stopper type, 4-5 line temperature measurement type, right angle L type, special shape, etc., according to the tube shell The temperature range is from 0-1000℃ for different materials.

Specification of cartridge oil heater:
1. Tube diameter: Φ3mm-Φ30mm,
2. The length of a single tube: 15mm-6000mm;
3. Material: iron, stainless steel, copper, titanium tube, imported materials;

Technical information of cartridge oil heater:
1. Operating conditions: ambient temperature -15℃-+60℃, relative temperature <80%;
2. Electric strength: 1500V50HZ in cold state withstand voltage working for 1MIN without breakdown;
4. Leakage current ≤0.5MA; insulation resistance ≥50MΩ;
5. Power deviation +5%, -10% or 10W, whichever is greater.
