Etched Foil Heater
Etched foil heater can be manufactured from etched foil The thickness of the etched heating sheet is usually a metal alloy foil with a thickness of 2.5-5 microns. The base material includes epoxy resin, polyimide and silicone rubber. Generally, the surface covering material is the same as the base material. The circuit pattern is vulcanized between two layers of silicon rubber and can be easily mounted to heat sinks or devices that need to be heated. Its flexibility can make your heater in the shape of flat, spiral wrap, blanket and so on. It can also be supplied with thermistors, thermostats, thermal fuses and thermocouples.
Technical Parameters
1.Size: Width10mm~1200mm* Length10mm~10000mm.
2.Thickness: 1~1.5mm.
3.Voltage: 1.5V~400V.
4.Power density: 0.03w/cm2~2.5w/cm2.
5.Using temperature: -60~250°C.
Features of Etched Foil Heater
1.Light weight.
2.Small size.
3.Thin thickness.
4.The temperature rises rapidly.
5. Convenient temperature control.
The edges of the heating sheets with complex shapes produced by the etching process have no burrs, no wrinkles on the surface, and the resistance value can be controlled within a stable range, with high yield, high efficiency and low price.
Advanges of Our Products
1.High security.
2.Stable quality.
3.Long service life.
4.Flexible in size and shape.
Etched foil heater has a wide range of uses. It can be used to heat almost any place where it is needed. The heater is pasted on the surface of the piece to be heated. Products with higher heat flux density can be customized where heat loss is great .Especially it can be installed in a relatively small space. Such as satellites and space vehicles, airplanes, portable instruments, electronic equipment, etc.
