Jaye Industry’s silicon rubber heaters are certificated by CE and UL. The heaters are using nickel resistance wire and normal silicon flexible and fiber glass material.
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of customized electric silicon rubber heater for wholesale in China, also supports custom service. Welcome to wholesale high quality customized electric silicon rubber heater for wholesale at competitive price from our factory.
Customized Electric Silicon Rubber Heater For Wholesale
Jaye Industry’s silicon rubber heaters are certificated by CE and UL. The heaters are using nickel resistance wire and normal silicon flexible and fiber glass material.
Detail specifications of the silicon rubber heater
Technical Parameters:
1) Maximum insulation temperature: 300 ℃
2) Maximum operating temperature: 250 ° C
3) Insulation resistance: ≥500 Megohm / DC 1000V
4) Breakdown voltage: ≥AC1500v / 5S
5) Capacity deviation: ± 5%
6) Temperature range: -60 ℃ -250 ℃ continuous heating, heating element: no matter what kind of browsing
Etched foil or winding elements:
7) Dimensions: maximum 1.2m × 15mm × 15mm Xm minimum; thickness 1.5mm (thinnest 0.8mm,
4.5 mm thick) Wire length: Standard 130 mm.
Customized sizes and popular sizes for European market
1.Silicon heater 400x800mm, 800W 230V
2.Silicon heater 450x450mm, 500W 230V
3.Silicon heater 190x200mm, 320W 230V
4.Silicon heater 100x200mm, 200W 230V
Applications
1. Outdoor equipments for heating and waterproof
2. Medical equipment and services
3. Oil drum heaters
4. Labrotary equipment
5. Industrial oven
Jaye industry supply best quality silicone rubber heating element mats and service. The silicone heating elements can be customized with different shapes, triangle heating mat, square heating mat, round heating mat with big size or small size as clients want. The voltage can be 220V, 230V, 240V, 110V, 120V for worldwide or low voltage 12V, 24V, 36V, 48V as you required.
