The KSD301 Snap-Action Thermostat is a small, inexpensive device designed to control temperature in a large number of applications. The KSD301 Snap-Action Thermostat is consistent and precise and can be designed to shut off or restore power to an appliance when the set temperature is reached to provide safe and dependable use. The KSD301 Snap-Action Thermostat will also enhance electricity efficiency and protect against overheating, both in the home and in more industrial situations. It is sturdy and complies with safety standards from around the globe, so the KSD301 Snap-Action Thermostat is a go-to choice for manufacturers. We can make the KSD301 Snap-Action Thermostat to suit your needs.
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of ksd301 snap-action thermostat in China, also supports custom service. Welcome to wholesale high quality ksd301 snap-action thermostat at competitive price from our factory.
The KSD301 Snap-Action Thermostat is a small, inexpensive device designed to control temperature in a large number of applications. The KSD301 Snap-Action Thermostat is consistent and precise and can be designed to shut off or restore power to an appliance when the set temperature is reached to provide safe and dependable use. The KSD301 Snap-Action Thermostat will also enhance electricity efficiency and protect against overheating, both in the home and in more industrial situations. It is sturdy and complies with safety standards from around the globe, so the KSD301 Snap-Action Thermostat is a go-to choice for manufacturers. We can make the KSD301 Snap-Action Thermostat to suit your needs.
| Model | KSD301 |
| Rated Voltage | 125V AC / 250V AC |
| Rated Current | 5A, 10A, 15A |
| Temperature Range | -30°C to 150°C (customizable up to 250°C for high-temperature models) |
| Temperature Tolerance | ±5°C |
| Function Type | Normally Closed (NC) / Normally Open (NO) |
| Insulation Resistance | ≥100MΩ (measured at 500V DC) |
| Dielectric Strength | 1500V AC for 1 minute (no breakdown) |
| Housing Material | Bakelite, Ceramic, or Metal (based on application requirements) |
| Terminal Types | Quick-connect tabs, solder terminals, or customized |
| Lifespan | ≥100,000 cycles (mechanical & electrical) |
1-Exact Temperature Control – the ability to react to temperature changes as they happen exactly.
2-Rugged Style – they use high quality materials lasting lasting a long time after being made.
3-User Setting – the used pre programmed temperature can be limited to -30°C to 150°C, but can have optional settings on up to 250°C.
4-NO and NC versions available – the item can be "normally open" or "normally closed".
5-Many uses – the items can be applied to anything from appliances to HVAC items to defrost systems, and more.
6-Cut-Off/Restore power for energy savings – prevents over heating by automatically cutting off and restoring power.
You can apply the KSD301 Snap-Action Thermostat into the follwing appliance:
1-Electric kettles
2-Water heaters
3-Coffee machines
4-Heating pads
5-Defrosting units
6-Medical equipment
