What Is a KSD9700 Thermal Protector? The KSD9700 thermal protector is a temperature-sensitive protection component designed to help prevent overheating in electrical equipment. For vacuum cleaner manufacturers, it can be incorporated into the motor protection circuit to help address excessive...
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of ksd9700 thermal protectors for vacuum cleaners in China, also supports custom service. Welcome to wholesale high quality ksd9700 thermal protectors for vacuum cleaners at competitive price from our factory.
The KSD9700 thermal protector is a temperature-sensitive protection component designed to help prevent overheating in electrical equipment.
For vacuum cleaner manufacturers, it can be incorporated into the motor protection circuit to help address excessive temperature caused by blocked airflow, abnormal loads, or other operating conditions.
JAYE provides thermal protection components for OEM applications, with product requirements evaluated according to customer specifications and equipment designs.
The following table provides reference specifications for the KSD9700 series. Actual values depend on the specific model and manufacturer and must be confirmed before ordering.
| Item | Reference Specification |
|---|---|
| Product model | KSD9700 series |
| Product type | Bimetallic thermal protector |
| Switching principle | Temperature-activated contact switching |
| Contact configuration | Normally closed (NC) or normally open (NO), depending on model |
| Operating temperature | Commonly available in multiple ratings; one published series lists 25–180°C |
| Reset temperature | Depends on operating-temperature rating and model |
| Rated voltage | Reference models: AC 125V / AC 250V |
| Rated current | Reference models: 8A at AC 125V / 5A at AC 250V |
| Service life | ≥10,000 cycles in the cited reference series |
| Housing material | Metal or plastic, depending on model |
| Lead wires | Configuration and length to be confirmed |
| Dimensions | Depend on housing and model |
Compact Design
The KSD9700 features a compact structure that can be installed in suitable motor housings and electrical equipment. The available dimensions and housing configuration should be checked against the installation space.
The bimetallic switching mechanism responds to temperature changes and operates at the specified trip temperature. This allows the protector to serve as part of a vacuum cleaner motor's overtemperature protection design.
Automatic Reset Options
Automatic-reset versions can restore the electrical connection after cooling to the specified reset temperature. The reset temperature and switching behavior depend on the selected model.
During normal vacuum cleaner operation, the motor generates heat that must be dissipated through the equipment's cooling design. If the suction passage becomes blocked or airflow is restricted, cooling conditions may deteriorate and the motor temperature may rise.
A suitably selected KSD9700 thermal protector can interrupt the circuit when the monitored temperature reaches its specified trip point, helping reduce the risk associated with excessive motor temperature.
Abnormal mechanical or electrical operating conditions may also increase motor temperature. A thermal protector provides temperature-based protection as part of the overall motor safety design.
The protector does not directly detect blockages or correct the cause of an abnormal load. Its effectiveness depends on the selected trip temperature, installation location, thermal coupling, and electrical circuit design.
For vacuum cleaner manufacturers and motor suppliers, the following details are useful when selecting a suitable thermal protector:
The required operating temperature should be evaluated against the motor's allowable temperature and the intended installation conditions. It should not be selected solely based on the vacuum cleaner's rated power.
The available operating temperatures depend on the product series and manufacturer. Published KSD9700 series data include multiple temperature ratings. Please confirm the required trip temperature and reset temperature for your application before ordering.
These ratings vary by model. Some published reference specifications list AC 125V/8A and AC 250V/5A. The actual rating must be verified for the selected model and the motor's electrical load.
Automatic-reset versions reconnect the contacts after the temperature falls to the specified reset level. Reset behavior depends on the selected model and should be confirmed before purchase.
Please provide the required operating and reset temperatures, voltage, current, contact configuration, dimensions, lead-wire requirements, and quantity. An existing sample, drawing, or clear photograph can also help us evaluate product compatibility and manufacturing feasibility.
