The temperature of this type of thermostat rises during operation, and the expansion of the liquid in the temperature sensing cylinder causes the displacement of the capsule. The displacement pushes the contacts off through the mechanical structure. After the temperature drops, the contacts are automatically turned on again. This mode is used to complete the control of temperature.
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of hydraulic capillary thermostat in China, also supports custom service. Welcome to wholesale high quality hydraulic capillary thermostat at competitive price from our factory.
The temperature of this type of thermostat rises during operation, and the expansion of the liquid in the temp. sensing cylinder causes the displacement of the capsule. The displacement pushes the contacts off through the mechanical structure. After the temp. drops, the contacts are automatically turned on again. This mode is used to complete the control of temperature.
Detailed Introduction:
Effective temperature range: maximum 350 degrees Celsius (the certain temp. can be set within the this range)
Maximum body temperature: 120 degrees Celsius
Rated power: 16A/250V AC; 25A/250V AC
Switching circuit (wiring form): SPST
Seat frame: screw and nut
Electric strength: AC1800V/0.5MA/1MIN
Terminal model: 45° angle
Thermostat weight: 45g
Sensor material: stainless steel (copper capillary can be selected), customized, PVC tube, fiber tube or fluorine plastic tube
Capillary length: you can choose a length of 250-2000mm (usually 1000mm)
Fixing screws: PT1/4" M12, M14 (optional)
If customers have special requirements, we can design and produce according to customers’ requirements
Features:
-This product needs to set the working temp. so as to operate at a fixed temp., which keep the temperature no change. This technology is widely used in products that prevent overheating or when only a specific temperature is adjusted.
-Its using temperature should be set in advance during production, it can reach 350°C at most, and can be used after setting according to the required temperature.
-High temperature accuracy, fast temperature sensing, reliable and simple action, and long service life.
