The thermostat is wired as a normally close circuit that closes when turn-on temp is reached. It is widely used for kitchen home appliance temp controlling. It has the advantages: the temperature tolerance is small when ON and OFF; accurate temperature control and wide adjustment scope.
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of temperature control switch capillary thermostat in China, also supports custom service. Welcome to wholesale high quality temperature control switch capillary thermostat at competitive price from our factory.
The thermostat is wired as a normally close circuit that closes when turn-on temp is reached. It is widely used for kitchen home appliance temp controlling. It has the advantages: the temperature tolerance is small when ON and OFF; accurate temperature control and wide adjustment scope.
Key Parameters of Temperature Control Switch Capillary Thermostat:
Temp. Range: 0-320 degrees Celsius
Probe Dia.:6mm
Probe Length: it is customized on different temp.
Rate Current/Voltage: AC16A 250V
Application Environment Temp.: T150
Length of Capillary Tube: 200-3000mm
On-off Temperature Difference: 2-12 degrees Celsius
Center Distance of Mounting Holes: 28mm with M4 screws
Applications: Oven, boiler, griddle, fryer, electric water heater, washing machine, etc. It is ideal for damaged part
Purchase Instructions:
1. The size of the shaft and its initial rotation angle need to be set according to customer needs.
2. The disconnection temp. and its performance curve need to be confirmed according to the customer's actual product and thermostat control matching test
3. All kinds of terminal sizes, specifications and directions are available, and the length of capillary tube and sheath tube can be selected by their own.
4. In order to install thermostats simply , it can also be welded different diameter of probe.
Customer satisfaction is our great passion, your satisfaction is 100% guaranteed! Please be free to contact us if you are not satisfied for any reason.
