At JAYE Heater Technology, we specialize in manufacturing high-quality PTFE immersion heaters with full customization options. With years of experience in the heating element industry, we deliver reliable, durable, and cost-effective solutions tailored to your specific application requirements
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of ptfe heater in China, also supports custom service. Welcome to wholesale high quality ptfe heater at competitive price from our factory.
PTFE (polytetrafluoroethylene), commonly known by the brand name Teflon, is a fluoropolymer with exceptional chemical resistance and thermal stability. PTFE heaters are electric heating elements coated with or wrapped in a PTFE sheath, designed specifically for heating corrosive liquids where metallic heaters would corrode, react, or contaminate the fluid. These heaters are the go-to choice for industries ranging from chemical processing and electroplating to semiconductor manufacturing and pharmaceutical production.
At JAYE Heater Technology, we specialize in manufacturing high-quality PTFE heaters with full customization options. With years of experience in the heating element industry, we deliver reliable, durable, and cost-effective solutions tailored to your specific application requirements.
| Power Rating | 100 W to 5,000+ W (customizable based on application) |
| Voltage | 220V, 380V, or custom |
| Tube Diameter | φ8mm, φ10mm, φ12mm, φ14mm, or custom |
| Heating Element Core | Nichrome alloy wire / Stainless steel (SUS304 or SUS316) |
| Outer Sheath | Heavy-wall PTFE (fluoropolymer) |
| Shape | Customizable – U-type, W-type, L-type, spiral, mosquito coil, combined, and more |
1. Exceptional Chemical Resistance
PTFE is inert to virtually all chemicals – acids, bases, solvents, and aggressive solutions. Unlike metallic heaters that pit, corrode, or release ions into the process fluid, PTFE heaters maintain their integrity even in the harshest environments. They are compatible with aqueous acids, alkaline solutions, anodizing baths, pickling solutions, and more.
2. Long Service Life with Low Watt Density Design
Our PTFE heaters feature a low watt density design (1.5 W/cm²) that minimizes surface temperature stress. This conservative approach significantly extends the operational life of the heater while ensuring uniform heat distribution throughout the process fluid.
3. High Thermal Stability
PTFE heaters can withstand continuous operation at temperatures up to 260°C (500°F) without degradation. This makes them suitable for a wide range of high-temperature process heating applications.
To place a custom order, we typically require the following information:
1-PTFE heater size
2-Type of liquid (acidic, alkaline, or other)
3-Maximum operating temperature required
4-Desired wattage and voltage
5-Wiring length and connection requirements
6-Shape and size preferences (drawings welcome)
PTFE heaters are widely used in industries where corrosive liquids, high purity, or contamination-free heating are critical. Common applications include:
1-Chemical Processing – heating acids, alkalis, solvents, and aggressive chemical baths; tank temperature maintenance; evaporation and freeze protection.
2-Electroplating & Metal Finishing – electroplating baths, electroless nickel plating, anodizing, pickling, degreasing, and electropolishing.
Semiconductor & Electronics – high-purity chemical heating, etching solutions, wet bench processing, wafer cleaning, and FPD/MEMS manufacturing.
3-Pharmaceutical & Biotechnology – sterilization, solvent heating, and CIP (clean-in-place) systems.
4-Water Treatment – heating brines, regeneration solutions, corrosive waste streams, and ultrapure water.
5-Industrial Cleaning – ultrasonic cleaning tanks with aggressive detergents and parts degreasing systems.
6Laboratory & Research – small-scale chemical heating and reaction vessel temperature control.
Ready to Find Your Perfect PTFE Heater?
Don't let corrosion and contamination compromise your process heating. Whether you need a single custom heater or a large-scale industrial solution, JAYE is here to help.
Contact us today to discuss your requirements.
